MOHAVE TECHNOLOGY

A10-RX

Two-Channel True Diversity Receiver

Overview

The two-channel A10-RX receiver is an advanced digital tool that works with either one or two A10-TX transmitters. With its Advanced Digital Diversity System the A10-RX receiver selects the best signal between each channel’s two receivers. When at the limits of system operation ADDS combines error-free digital packets from each receiver. This results in lossless, wireless digital audio up to the absolute limits of operation.

The A10-RX is offered in two versions, the A10-RX-SL for uni- and Superslot mounting, and the A10-RX-XLR for stand-alone operation in a production bag.

  • Two-channel, wideband receiver with worldwide tuning range of 470 MHz – 694 MHz
  • Advanced Digital Diversity topology uses two complete RF receivers for each of the two channels, with four RF receivers in total
  • State-of-the-art 100% digital long-range modulation delivers the longest transmission distance of any system on the market
  • Simple menus are quick to access
  • Quality meter provides additional information about the RF spectrum so you can quickly adapt to interference and avoid dropouts or poor performance
  • Available in both slot (Uni-/SuperSlot) with the A10-RX-SL or stand-alone cabled version with the A10-RX-XLR
  • Analogue line-level or AES3 digital audio output
  • Compatible with select Sony camera models with A-15PIN. This collaboration between Sony and Sound Devices allows the A10-RX receiver to pass two channel digital audio internally on the Sony camcorder, negating the need for any external cables
Specifications
  • Operating Frequency Range : 470-694MHz
  • A10-RX in two versions : the A10-RX-SL & A10-RX-XLR
