DA04

Lavalier Microphone

Products Available

• DA04 BE Lavalier microphone, -45dB Omni, Beige
• DA04 BL Lavalier microphone, -45dB Omni, Black

Key Features

• Element: Back Electret Condenser
• Polar Pattern: Omnidirectional
• Frequency Response: 20Hz – 20Khz
• Sensitivity: -45dB ±3dB
• Output Impedance: 2Kohms ±30%
• SPL Max: 140dB
• Equivalent Noise Level (A-Weighted): 32dB
• Dynamic Range: 123.5dB – 31dB = 92.5dB
• Optimum Output Level: 123.5dB SPL @ 3%THD
• Operating Voltage: 0.9V (optimal) – 5V (Maximum)
• Cable: 1.4mm*1.8m
• Weight: 4g (Mic inc. cable only)
• Mic Dimension: 3.5mm
